HappyModel X12 AIO Whoop Flight Controller ELRS 2S F4 FC + 12A 4IN1 ESC 25-400mW VTX 25x25mm (ELRS 2.4G)
The HappyModel X12 2S AIO Whoop Flight Controller (F4 FC / 12A 4in1 ESC / 25-400mW VTX) AIO board featuring an F4 Flight Controller, onboard 12A 4-in-1 ESC, 5.8GHz OpenVTX and built-in receiver of your choice! Happymodel continues to impress with yet another fantastic AIO for whoop applications!
Specifications
- Input Voltage: 1-2S
- MCU: STM32F411CEU6 (100MHZ, 512K FLASH)
- Gyro: MPU6000 or ICM20689 or BMI270
- Max Continuous Current: 12A
- VTX Output Power: 25-400mW
- Antenna Connector: U.FL
- OSD: Yes
- Betaflight Target: ELRS Version: CRAZYBEEF4SX1280, PNP Version: CRAZYBEEF4DX
- ESC Firmware: Z_H_30_REV16_7
- Mounting Pattern: 25x25mm
- Weight: 5.1g
ELRS Version
- Packet Rate: 50Hz/150Hz/250Hz/500Hz
- ELRS Firmware Version: V2.0
- RF Frequency: 2.4GHz
- Antenna: SMD antenna
- Telemetry output Power: <12dBm
Includes
- 1x HappyModel X12 2S AIO Whoop Flight Controller (F4 FC / 12A 4in1 ESC / 25-400mW VTX)
- 1x Connecting Wires Set
- 1x Hardware Set
- 1x Antenna
